Condition:
New
Range Of Spindle Speed(r.p.m):
1 - 24000 Rpm
Positioning Accuracy (mm):
0.01 Mm
Number Of Axes:
Oth
No. Of Spindles:
ATC
Working Table Size(mm):
2000×3000
Machine Type:
CNC Router
Travel (X Axis)(mm):
2000 Mm
Travel (Y Axis)(mm):
3000 Mm
Repeatability (X/Y/Z) (mm):
0.01 Mm
Spindle Motor Power(kW):
9.0KW
CNC Or Not:
CNC
Voltage:
AC380V/60Hz
Dimension(L*W*H):
2000*3000mm
Power (kW):
25
Weight (KG):
2500
Control System Brand:
Syntec
Warranty:
2 Years
Key Selling Points:
Multifunctional
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Home Use, Advertising Company
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
2 Years
Core Components:
Bearing, Motor, Pump, Gear, Engine, Gearbox
Operating System:
Sytnec 6MB Control System
Cooling Mode:
Air Cooling
Motor And Driver:
Japanese Yaskawa Servo
Inverter:
Fuling Inverter
Spindle:
China HQD 9.0KW
Table:
Vacuum Table And T-solt Table
Guide Rail:
Taiwan Hiwin Square Guide Rail
Control System:
Syntec Control System
Application:
Wood Working
Software:
Ucancam / ArtCam/TYPE3
